3 Phase Relay Test Kit

Link Copied

Edit

Business Type	Manufacturer, Exporter, Trader
Click Here to View Catalogue	View
Country of Origin	India
Input	440V, 3 PHASE supply, 50Hz
Click to view more

Preferred Buyer From

Location

Anywhere in India

Product Details

Output

Three Phase Current O/p 1) 0 30 Amp each phase

AC Volt Output

Con􀀈nuously variable 0 230V Capacity 150 VA (Max) Single Phase

Time Measurement

0 0.001 to 9999 Sec in four ranges

Measuring CT

Mul􀀈 ra􀀈o wound primary current transformer

Current Metering

Digital Meter Basic Range : 0 1A AC Scaled in 0 to 100% for all selected range Accuracy : 1.5% of FS

Features :

Potentoal free
start and stop signal
Continuously adjustable outputs
Portable Models
Digital Ammeter, Voltmeter and time interval meter (Unitimer) UniTimer automatically puts OFF the output, when timer reaches to its maximum value of the selected range to ensure safety of the instruments as well as the item under test. Wide range of measurement, i.e. From 0. 001 second. To 9999 Seconds
